Clyde 3 Bed Lodge | 15x6m

Bright, Open, and Spacious: The Clyde 15x6m

The Clyde 15x6m Lodge is the perfect middle-ground in our luxury residential range. By extending the length to 15 metres, we have increased the internal floor area to 82.2 square metres, providing that crucial extra space for larger bedrooms and a more relaxed open-plan living environment compared to the 14m model.

Designed for Views

What sets this specific 15m model apart is the glazing package. It is designed to capture the view. It features four massive floor-to-lintel windows (1330x1770mm)—significantly more than smaller models.

• Natural Light: The main living area is bathed in sunlight, creating a connection between the indoors and your garden or landscape.

• Practicality: Complementing the large glass panels are specific windows for functionality, including wide, shallow windows (1200x600mm) perfect for positioning above kitchen worktops.

Engineered for Year-Round Living

As with all our premium lodges, the Clyde 15x6m is built to last:

• 88mm Glulam Logs: The walls are constructed from glue-laminated timber, providing superior thermal mass and structural rigidity over the 15-metre span.

• Dual Access: A main double glass door welcomes guests, while a secondary single glass door offers practical side access for mudrooms or utility areas.

• Heavy Duty Build: From the 135mm floor bearers to the 7 heavy-duty roof purlins, every component is sized for permanent residency.

Key Features & Specifications
Below is the detailed technical specification for the Clyde 15x6m Lodge. Note the upgraded window count and the substantial 82.2m² living area.

Dimensions & Area

Overall Dimensions: 6000 mm x 15000 mm (6m x 15m)
Internal Dimensions: 5624 mm x 14624 mm
Total Inside Area: 82.2 m² (Spacious 3-Bed)
Sidewall Height: 2340 mm
Ridge Height: 3250 mm

Construction Materials

Wall Logs: 88mm Glulam (Superior stability)
Internal Partition Walls: 88mm Glulam
Floor Bearers: Heavy Duty 135mm x 135mm
Floorboards: 28mm Tongue and Groove

Roof Structure

Roof Pitch: 17.20°
Roof Purlins: 88mm x 260mm (7 Units)
Roof Area: 122.1 m²

Insulation Prep: Double Roof Preparation (100mm Insulation gap)

Windows & Doors (Living Type - 68mm)
Window Quality: "Living Type" 68mm Frame (Double Glazed)
Large Feature Windows: 4 Units (1330x1770mm) – High impact glazing
Standard Living Windows: 3 Units (1330x990mm)
Kitchen/Wide Windows: 2 Units (1200x600mm)
Small/Bathroom Window: 1 Unit (580x600mm)
Main Entrance: 1 Unit Double Full Glass Door (1400x2030mm)
Side Entrance: 1 Unit Single Full Glass Door (900x2030mm)
Internal Doors: 5 Units Solid Wood Doors (900x2030mm)
